Cross clevis SH195.1
Cross clevis can be used e.g. in the upper end of SH193 insulator string when the string's eye ball cannot be directly attached to crossarm or pole structure.
| Code | SH195.1 |
| GTIN | 6418677407086 |
| Name | Cross clevis Clevis = 18 mm |
| Dimensions | |
|---|---|
| Weight | 0.42 kg |
| Height | 22 mm |
| Width | 77 mm |
| Length | 93 mm |
| ETIM | |
| ETIM Class | EC003516 |
| Type of accessory/spare part | Other |
| Carton | |
|---|---|
| Size | 25 pcs |
| Depth | 224 mm |
| Height | 188 mm |
| Width | 224 mm |
| Weight | 10.738 kg |
| Volume | 9.433088 l |
| Pallet package | |
| Size | 1875 pcs |
| Depth | 1200 mm |
| Height | 1090 mm |
| Width | 800 mm |
| Weight | 825.350 kg |
| Volume | 1046.4 l |
