Stay wire clamp automatic COL25
Automatic stay wire clamp are used for steel stay wire or steel messenger wire. COL dead ends are guaranteed to hold a minimum of 90% of the rated strength of the steel wire.
| Code | COL25 |
| GTIN | 6418677418495 |
| Name | Stay wire clamp automatic Fe 5.5-6.9 mm, Fe 25 mm² |
| Dimensions | |
|---|---|
| Weight | 0.236 kg |
| Conductor diameter | 5.46 ... 6.86 mm |
| Features | |
| For conductor size | Fe 25 |
| ETIM | |
| ETIM Class | EC003513 |
| Type of accessory/spare part | Automatic dead end |
| Material | Other |
| Surface protection | Other |
| UV resistant | Yes |
| Cross section | ≥ 25 mm² |
| Insulator | No |
| Plastic bag | |
|---|---|
| Size | 1 pce |
| Depth | 165 mm |
| Height | 50 mm |
| Width | 60 mm |
| Weight | 0.256 kg |
| Volume | 0.495 l |
| Carton | |
| Size | 50 pcs |
| Depth | 375 mm |
| Height | 157 mm |
| Width | 250 mm |
| Weight | 13.042 kg |
| Volume | 14.71875 l |
| Pallet package | |
| Size | 2700 pcs |
| Depth | 1200 mm |
| Height | 1092 mm |
| Width | 800 mm |
| Weight | 724.268 kg |
| Volume | 1048.32 l |
