Cable connector mechanical C1000MSB6

Cable connector mechanical C1000MSB6

The connector is used for jointing conductors of cables up to 42 kV. Because of the shear head bolt construction, no crimping tools are needed. The required torque is achieved by tightening the bolt until it breaks off. The connector is longitudinally watertight. It is suitable for aluminium and copper conductors: solid and stranded, sector shaped and circular. The cable core insulation may be plastic or paper.

Code C1000MSB6
GTIN 6438389022469
Name Cable connector mechanical
Al/Cu 500-1000 kcmil
Contact sales

Technical information

Technical specifications

Standards IEC 61238-1-3:2018
Conductor material Al/Cu
Weight 1.7 lb
Height 2.63 in
Width 1.85 in
Length 6.1 in
For conductor shape Stranded,Solid,Sector,Round
Cross section solid circular US 500 kcmil - 1000 kcmil
Cross section stranded circular US 500 kcmil - 1000 kcmil
Conductor hole diameter US 1.2 in

Packaging

Carton
Size 6 pcs
Depth 8.26 in
Height 6.29 in
Width 8.26 in
Weight 10.88 lb
Volume 1.86 gal
